Tough & Durable Engineering Resin | 355nm High-Strength SLA Material | Supermaker
By Supermaker
Supermaker 355nm Engineering Resin is a high-performance photopolymer for functional prototypes and end-use parts. It delivers high strength, rigidity, and thermal stability, making it ideal for jigs, fixtures, and consumer product testing. This material excels in durable concept modeling and tough engineering applications, offering superior performance over standard resins.
355nm Engineering Resin
Color:
Yellow
Density:
1.11-~1.15g/cm3 @ 25 ℃
Viscosity:
248~328 cps @ 26℃
Penetration Depth:
0.14~0.16 mm
Critical Exposure:
8.1~9.1mJ/cm2
Building layer thickness:
0.05~0.12mm
Hardness(Shore D):
78~89
Flexural modulus (Mpa):
2,715-2,825
Flexural strength (Mpa):
73-81
Tensile modulus (Mpa):
2,701-2,865
Tensile strength (MPa):
49-61
Elongation at break:
10-15%
Poisson's Ratio:
0.40-0.45
Impact strength notched Izod(J/m):
30-38
Heat Deflection temperature(℃):
67~78℃
Glass transition(Tg):
71~83
Coefficient of thermal expension:
85~99*E-6
Dielectric Constant 60 Hz:
4.1~5.1
Dielectric Constant 1kHz:
3.4~4.2
Dielectric Constant 1MHz:
3.1~4.1
Dielectric Strength kV/mm:
12.7~16.9
