Upgraded 355nm High-Temperature Resin | For Under-Hood Parts & Hot Fluid Fixtures | Supermaker
By Supermaker
Delivers superior thermal stability for demanding applications. This advanced formula offers an increased heat deflection temperature (HDT), perfect for hot air ducts, engine compartment prototypes, and heat-resistant molds. It maintains dimensional stability under thermal stress, making it ideal for functional testing, custom tooling, and high-temperature end-use parts. Achieve exceptional performance in extreme environments with this reliable engineering material.
355nm Upgraded High-Temp Resin
Color:
White
Density:
1.11~1.15g/cm3 @ 25 ℃
Viscosity:
450~530 cps @ 27℃
Penetration Depth:
0.14~0.16 mm
Critical Exposure:
7.1~8.1 mJ/cm2
Building layer thickness:
0.05~0.12mm
Hardness(Shore D):
87
Flexural modulus (Mpa):
3832
Flexural strength (Mpa):
82
Tensile modulus (Mpa):
2,621-2,775
Tensile strength (MPa):
44-56
Elongation at break:
7%
Poisson's Ratio:
0.40-0.45
Impact strength notched Izod(J/m):
29-39
Heat Deflection temperature(℃):
170℃
Glass transition(Tg):
102
Coefficient of thermal expension:
85~99*E-6
Dielectric Constant 60 Hz:
4.1~5.1
Dielectric Constant 1kHz:
3.4~4.2
Dielectric Constant 1MHz:
3.1~4.1
Dielectric Strength kV/mm:
12.7~16.9
